Multiplespring Mechanical Seal Manufacturer Supplier

Pressure: 18 Bars(max)

Shaft Diameter: 19 To 100 Mm

Temperature: -20 To +350°C

Seal Ring Face: Carbon, SiC & T.C

Seat Face: SiC & T.C

Pressure: 18 Bars(max)

Shaft Diameter: 19 To 100 Mm

Temperature: -20 To +350°C

Velocity: Up to 20 m/sec / 3000 r.p.m

Seal Ring Face: Carbon, SiC & T.C

Pressure: 16 Bars(max)

Shaft Diameter: 19 To 100 Mm

Temperature: -40 To +220°C

Seal Ring Face: Carbon, SiC & T.C

Seat Face: SiC & T.C

Velocity: Up To 20 M/sec / 3000 R.p.m.

Replaceable Face: GFT, CFT, SiFT

Shaft Diameter: 18 to 100 mm

Pressure: 8 Bars(max)

Temperature: -40 to +160°C

Velocity: Up To 20 M/sec / 3000 R.p.m.

Non Replaceable Face: GFT & CFT

Shaft Diameter: 18 to 100 mm

Pressure: 8 Bars(max)

Temperature: -45 to +160°C

Temperature: -20 to +100°C

Velocity: Up to 10 m/sec / 1450 r.p.m.

Seal Ring Face: Carbon, SiC & T.C

Seat Face: Ceramic, SiC & T.C

Elastomer: Viton, Neoprene, EPDM, NBR and Buna-N
